Stretch film machine/Cling Film Machine
Name: Julie Lee
Tel: +86-750-55235626
Fax: +86-750-55235627
Mobile: +86-13926531711
E-mail: kingplas@hotmail.com
Add: Taishan Industrial Park,Jiangmen City,Guangdong Province
Skype: kingplas@hotmail.com
WeChat: 13926531711
whatsapp: +86-13926531711
QQ:
365394497
1.Fully automatic Stretch film rewinding machine is used to rewind the jumbo roll film into small roll.It is a kind of multi-function machine integrated with rewinding.meter counting and automatic out-off.
2.Automatic cutting,automatic rewinding,automatic Collection
3.PLC control with inverter,which is easy operating and safe.
Main Technical Data:
|
Model |
500 |
|
Width of finished product(mm) |
500 |
|
Main motor(kw) |
4 |
|
Swing Motor |
0.37kw |
|
Line speed(m/min) |
800 |
|
Roll Laying Mode(mm) |
Automatic |
|
Diameter of parent roll(max)(mm) |
350 |
|
Width of parent roll (max)(mm) |
500 |
|
Core specification of parent roll |
3” |
|
Cutting mode |
by resistance wire |
|
Width of sub-roll (max)(mm) |
500 |
|
Diameter of sub-roll (max)(mm) |
150 |
|
Core specification of sub-roll |
2”+3” |
|
Overall dimensions(L×W×H)(m) |
2.6×1.8×1.4 |
|
Weight(T) |
0.8T |
|
