Specifications

  The full auto pre-stretch film rewinding machine designed for the rapid converting of stretch film or cling film from longer jumbo roll into shorter small roll. The machine have two function.

  1- It can be use as automatic rewinding function.
  2- It have auto pre-stretched function                                                                             .

  3- Paper core feeding: automatically

  4- Film cutting: automatically

  5- Roll exchanging: automatically

  6- High speed rewinding from 0-600m/min

  7- Full auto working step by PLC program.

  8- HMI friendly operation. Set different length is easy.

Model

600

Width of material

300-600mm

Thickness of material

7-50micro

Speed

0-600m/min

Mother Roll Diameter(max)

400mm

Finished Roll Diameter(max)

180mm

Paper core ID for unwinder

3”

Paper core ID for rewinder

2” 3”

Pre-stretched ratio

100-300%

Dimension

1450*1400*1500mm

Product Show
Pre Stretch Film Machine
Pre Stretch Film Machine
