Usage of plastic crusher machine :
Widely used in various kinds of plastic,such as plastic box ,film ,plastic pipe ,plastic briquette and waste plastic ,and waste rubber .
Structure of plastic crusher machine:
The body is mainly made of stainless steel ,which can have a durable specification and has a long life time .
Working Principle of plastic crusher machine:
Using the rotation of the rotary blades and squeeze with the fixed blades ,so that big material can be crushed into small size,the hole of the sieve is among 8-14mm.
Installation of the power plastic crusher machine :
1.The plastic crushing machine should be firmly installed ,if needn’t move We should fixed it by cement .If need mobile operation , We should find some angle shelf to fixed .
Model |
Crusher chamber |
Crushing Ability(Kg/h) |
Motor |
Stationary blade |
Rotary blade |
Machine Dimension(mm) |
Weight(Kg) |
160 |
150*160 |
100-150 |
1.5/2.2 |
2 |
6 |
660*380*950 |
140 |
250 |
190*250 |
150-200 |
4 |
2 |
9 |
900*640*1050 |
220 |
300 |
230*300 |
200-250 |
5.5 |
2 |
12 |
1030*750*1200 |
360 |
400 |
245*400 |
300-450 |
7.5 |
2 |
12 |
1100*860*1330 |
420 |
500 |
300*500 |
400-800 |
11 |
2 |
15 |
1300*1020*1520 |
600 |
600 |
335*600 |
450-900 |
15 |
4 |
18 |
1450*1155*1700 |
800 |
800 |
500*800 |
650-1300 |
22-37 |
4 |
24 |
1850*1410*2130 |
2000 |
2.After start the plastic crushing machine ,We should keep it without feed any material for 2-3min ,make sure it has a normal working condition .
Edge Cutting Machine For Cling Film
This machine is designed for cutting both ends of PE OR PVC Cling film roll to make them level and beautiful,cause the film roll is a little split-level and irregular after air removal .
Model |
250mm |
300mm |
Max applicable roll diameter (mm) |
250 |
300 |
Applicable width range (mm) |
200~450 |
250~450 |
Core size (inch ) |
3" |
3" |
Total power (KW) |
2.5 |
3 |
Weight (T) |
0.5 |
0.5 |
Overall dimensions (L*W*H)M |
1.4*1*1.6 |
1.4*1*1.6 |
