KINGPLAS MACHINERY CO.,LTD



1- T-die adopts imported top special mould steel, by the high-precision process and treatment to ensure the long-term use of non-die deformation, and material extrusion more smooth and stable.

 2- The screw adopts special mixing function and high plasticizing design which combine import static mixer to ensure plasticization is great, color is uniform and increase extrusion capacity greatly.

 3- The temperature is controlled by automatic temperature controller, which can accurately control the plasticizing process. All of the temperature controller match with solid relay.
 4- The Extrusion speed, Drawing speed, Winding speed are controlled by Inverter.
 5- Automatic feeding and on line recycling material.The machine equipped with digital meter counter to control the length of the film automaticly.
 6- Full automatically winder exchanging system and controlled by PLC program

Model

45/55*650

55/75*1250

65/90*1850

Layers

AB/ABA

ABA

ABA

Screw diameter

45mm/55mm

55mm/75mm

65mm/90mm

Screw L/D ratio

30:1

30:1

30:1

Screw speed

20-150rpm

20-150rpm

20-150rpm

Max output

70kg/hr

150kg/hr

180kg/hr

Finished Film Width

500mm

1000mm/2*500mm/2*450mm

1500mm/3*500mm/3*450mm

Thickness

0.01-0.05mm

0.01-0.05mm

0.01-0.05mm

Total power

35kw

70kw

100kw

Consumption power

15-20kw/h

25kw-30kw/h

30kw-35kw/h

Dimensionmm)

4700*1850*3000

6500*3000*3000

8000*3000*3000

Weight

5000kg

6500kg

7500kg

Product Show
2 Layer Stretch Film Machine

  2 Layer Stretch Film Machine

 1- T-die adopts imported top special mould steel, by the high-precision process and treatment to ensure the long-term use of non-die deformation...
